Section 2 Installation H85A Manual
www.rottlermfg.com
2-3
IF VOLTAGE IS OUTSIDE THE CORRECT RANGE AT ANY TIME THE
MACHINE WILL NOT OPERATE PROPERLY AND MAY BE DAMAGED.
______Briey describe the isolated ground connection to the machine you have made: (Instructions to
make a correct isolated ground are included in the operating manual)
_____________________________________________________________________________
_____________________________________________________________________________
_____________________________________________________________________________
______Customer should attempt to have junk work piece available.
______Make sure coolant will be available for set up.
______Have the operator read through the operation manual before training begins. This will help him
be familiar with the button pushing sequences. Have the operator read through the manual again
after training and some of the sequences will make more sense.
______Clean any rust inhibitor from the machine surfaces
______Make sure that an Internet connection is available at the machine.
The following is the Rottler Sales/Service technician’s responsibility
MACHINE START-UP
______BEFORE turning power on to the machine. Check all wires for security by using the correct screw
driver and turning CW until movement stops. Stranded wire can “spread” slightly from vibration
during transport.
______Install electrical component covers inside the electrical enclosure with fasteners provided.
______The system is protected by fuses and circuit breakers located in the electrical enclosure. Show
customer where they are located and conrm that spare fuses were shipped with machine.
When starting the machine for the rst time, it may move out of control. Make
sure all hands are clear of machine parts. Be ready to press the Emergency
Stop button if needed.
______Explain the coolant ltration system and necessity of maintenance to that system.
______Explain to the customer the injection oiler operation. The timer is controlled by the computer.
Show the customer where the reservoir is located and explain what type of oil is required.
______Turn Main power on at the power switch located on the electrical enclosure.
______If any of the fuses blow, replace them, then call factory if further assistance is needed.
______If any of the circuit breakers “trip”, reset and call factory for possible trouble shooting.
______If machine moves out of control, turn power off and contact factory for help in trouble shooting.
______Install and test the Internet connection to the machine. DO NOT download any updates unless
instructed to do so by Rottler.
______Check oil lines to make sure they are fully primed. On machines with enclosure the back access
panel will have to be removed. If oil lines are not fully primed with oil, run the manual priming
procedure as described in maintenance section of the manual.
MACHINE MOVEMENTS
______Remove hone head from machine for the following procedures.
______Verify all machine movements are working correctly using the hand wheel.
______Verify all machine movements are working correctly using the jog buttons.
______Start spindle motor to verify correct direction of rotation.
