Getting to Know the Access Point Features
SmartCell SC8800-S Outdoor Access Point
Ruckus Wireless Outdoor AP 100.1.0 User Guide, 800-70863-001 Rev A 18
3
AIR
LED • Off: The AP is operating in standalone mode or operating as a
root AP (RAP) or a non-mesh AP.
•
Solid Green: The AP is functioning as a Mesh AP (MAP) and the
uplink signal quality is good (>24dBm).
•
Fast Flashing Green (twice per second): The AP is functioning
as a Mesh AP (MAP) and the wireless signal to its uplink AP is fair.
•
Slow Flashing Green (once every two seconds): The AP is in
mesh mode, but the AP is still searching for a mesh uplink.
4
2.4G
LED • Off: WLAN service is down.
•
Amber (Yellow): WLAN service is up but with no client
connected.
•
Solid Green: WLAN service is up with at least one client
connected.
5
5G
LED • Off: WLAN service is down.
•
Amber (Yellow): WLAN service is up but with no clients or
downlink MAPs associated/connected.
•
Solid Green: WLAN service is up with at least one client is
associated. No downlink MAPs are connected.
•
Fast Flashing Green (twice per second): The WLAN is up, at
least one downlink MAP is connected, and at least one client is
associated.
•
Slow Flashing Green (once every two seconds): The WLAN is
up and at least one downlink MAP is connected. No clients are
associated.
Table 5. SC8800-S LED descriptions (Continued)
No. Label Description
