Annex G - Connector Technology
Page G-2 F@ST 4310 Reference Manual
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
G.1 Pinouts of the LINE connector
The equipment is connected to ADSL using a RJ11 fixed connector (6 pins).
Contact N° Signal Meaning
3 LINE-A Line A signal
4 LINE-B Line B signal
1 NC Not connected
2 NC Not connected
5 NC Not connected
6 NC Not connected
