5- Information / Configuration
F@ST 4310 Reference Manual Page 5-5
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
5.3 ADSL connection status
Refer to subsection 6.2.1 - /Summary.
5.4 Display frame
The router’s activity status is always visible at the left corner or the top right of the HTTP configuration tool.
You can perform the following actions:
• click on Refresh to update the data displayed
• click on Reboot to restart your router
ADSL information
The following table presents the possible states of the ADSL field:
The Down field displays the nominal downlink bit rate.
The Up field displays the nominal uplink bit rate.
Internet information
The following table presents the possible states of the Internet field:
Status Meaning
Green ADSL line synchronised
Yellow ADSL line synchronising
Red ADSL line not connected
Status Status Meaning
Off
ADSL Down ADSL line not connected or not activated
Not configured The Internet account must be configured
Router rebooting Router is rebooting
Green Connected The Internet connection has succeeded
Yellow Waiting for ISP Connecting to the Internet service
Red Access denied Incorrect Internet account
