SAGEMCOM F@ST 4310 User Manual

5- Information / Configuration
F@ST 4310 Reference Manual Page 5-27
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
• Click on the Next button to continue configuring the remote network (WAN) in PPPoE mode.
Inactivity Timeout
(minutes):[1-4320]
a
Enter the inactivity time. This value (in minutes) is between 1
and 4320 (i.e. 72 hours).
If there is no Internet traffic for this period of time, the PPPoE
session is interrupted.
0
PPP retry on
authentication error
Check the box, PPP can be retried again and again while
authentication fails.
Checked
PPP retry period
(seconds) ):[3-65535]
b
Enter if required a retry period. This value (in seconds) is by
default set to 15 seconds. You can set another value from 3 to
65535.
15
PPP MTU (Bytes)
Enter an MTU (Maximum Transfer Unit) value. This value (in
bytes) is between 38 and 1492.
Note: The MTU specifies the maximum size of the data used
(IP packets) expressed as a number of bytes.
1492
Use Static IPv4 Address
Check the box to use the static IPv4 address. Not
checked
IPv4 Address
c
Enter the static IPv4 address. 0.0.0.0
Enable PPP Debug
mode
Check the box to use the PPP Debug mode.
In the event of connection failure, this option will enable you to
trace a possible problem in the SYSLOG file.
Not
checked
Bridge PPPoE frames
between WAN and Local
Ports
Check the box to enable the router when bridging the frames
between WAN and local Ethernet ports.
Not
checked
Enable IGMP Multicast
Proxy
Check the box to activate the IGMP function. Not
checked
a. This field only appears when the "PPP retry on authentication error" field is activated (box checked).
b. This field only appears when the "PPP retry on authentication error" field is activated (box checked).
c. This field only appears when the "Use Static IPv4 Address" field is activated (box checked).
Field Action
Default
value
