SAGEMCOM F@ST 4310 User Manual

5- Information / Configuration
F@ST 4310 Reference Manual Page 5-39
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
• Click on the Next button to continue configuring the remote network (WAN) in PPPoA mode.
• Select a preferred WAN interface as the system default gateway.
PPP MTU (Bytes)
Enter an MTU (Maximum Transfer Unit) value. This value (in
bytes) is between 46 and 1500.
Note: The MTU specifies the maximum size of the data used
(IP packets) expressed as a number of bytes.
1500
Use Static IPv4 Address
Check the box to use the static IPv4 address. Not
checked
IPv4 Address:
b
Enter the static IPv4 address. 0.0.0.0
Enable PPP Debug
Mode
Check the box to use the PPP Debug mode.
In the event of connection failure, this option will enable you to
trace a possible problem in the SYSLOG file.
Not
checked
Enable IGMP Multicast
Proxy
Check the box to activate the IGMP function. Not
checked
a. This field only appears when the "PPP retry on authentication error" field is activated (box checked).
b. This field only appears when the "Use Static IPv4 Address" field is activated (box checked).
Field Action
Default
value
