PLC Wireless Router F@st Plug 502W
- 85 -
Ethernet Port 2 x RJ45 for 10/100 Ethernet (Auto MDI/MDI-X)
Antenna PCB-Antenna x 2
Button
Security: Set the status of device members.
Reset: Restore factory default settings.
WPS: Press this pushbutton for less than 3 seconds to
enable the negotiation of PBC mode. Press this pushbutton
for more than 5 seconds to enable or disable WLAN.
Software Upgrade Support software upgrade by Web page.
Consumption 6.5 W
Environment Requirements
Operating Temperature 0~40ºC
Storage Temperature -10~70ºC
Operating Humidity 10%~85%, non-condensing
Storage Humidity 5%~90%, non-condensing
Rated Input 100~240 V AC, 50/60 Hz
EMC and Safety
Compliance FCC Part 15 Class B, CE
Safety Authentication UL
Green Standard RoHS
Physical Characteristics
Dimension L × W × H: 107 mm × 62 mm × 48.5 mm
Weight 180 g
