F@st Plug 502W PLC Wireless Router
- 84 -
Specifications
PLC Module Specification
Chip Qualcomm ATHEROS AR7420/AR1540
Firmware Support North America/Europe/APAC/Japan
Protocol
HomePlug AV
IEEE1901
IEEE 802.3 10/100 Ethernet (100 Mbps)
IEEE 802.3u Fast Ethernet
PLC Rate 500 Mbps
Signal Band 2~68 MHz
Modulation Mode
Support OFDM 4096/1024/256/64/16/8-QAM, QPSK, BPSK,
and ROBO
Encryption 128-bit AES
QoS
Support four-level QoS
Support VLAN priority
Support ToS and CoS packet classifications
Operation Mode Support priority-based CSMA/CA channel access scheme
Multicast Support IGMP management multicast session
Wi-Fi Module Specification
Chip Qualcomm Atheros AR9341
Flash Memory 64 Mbps
DDR SDRAM: 256 Mbps
Protocol
IEEE 802.11b/g/n
IEEE 802.3/3x/3u
Wireless Frequency
Range
2.4 GHz~2.484 GHz
Channel 1~13
Wireless Signal Rate
11b: 11/5.5/2/1 Mbps
11g: 54/48/36/24/18/12/9/6 Mbps
11n: up to 300 Mbps in 40 MHz mode and up to 144.4 Mbps
in 20 MHz mode.
Output Power
11b: 16~17 dBm
11g: 14~17 dBm
11n: 11~16 dBm
Receiving Sensitivity
11b: 11 Mbps/-76 dBM
11g: 54 Mbps/-65 dBm
11n: 150 Mbps/-64 dBM
Operation Mode 2Tx/2Rx
Multiple SSID 1 BSSID
Security Authentication
WEP, WPA, WPA2 and WPA/WPA2 Mixed
SSID hiding
MAC address access control list
System Specification
LED Indicator
Power: Indicate power status.
LAN1/LAN2: Indicate the connection status of LAN1
interface or LAN2 interface.
Data: Indicate PLC rate.
WLAN: Indicate WLAN ON/OFF status and WPS connection
status.
Power Socket Support power sockets of English-style and European-style
