Salus AX10RF - AS20 WRF;BRF Thermostat - Functions & Parameters

7.3
Function
Parameters
Description
Default Value
d00 Select Units 0
0 SI Metric Units - °C
1 US Customary Units - °F
d01 Heating Control 0
0 Time Proportional & Integral (TPI)
1 ON/OFF – 0.5°C (1.0°F) Increments
2 ON/OFF – 1.0°C (2.0°F) increments
d02 Temp. Oset 0
-6ºF to +6ºF
(-3.0ºC to +3.0ºC )
Room Temperature Oset (1.0°F/0.5°C increments)
d03 Outdoor Sensor 0
0 Outdoor Sensor not connected to S1/S2
1 Outdoor Sensor or Ext. (d04) connected (10 kΩ)
3 Not Used
d04 External Sensor 0
0 d03 = 1, Ext. air sensor active, Int. sensor inactive
1 d03 = 1, Ext. oor sensor active, Int. sensor active
d05 Cooling Control 2
1 ON/OFF – 1.0°F (0.5°C) increments
2 ON/OFF – 2.0°F (1.0°C ) increments
d06 Actuator Type 1
0 NO Normally Open
1 NC Normally Closed
d07 Valve Protection 1
0 ARV10RFM Valve Exercise Disable
1 ARV10RFM Valve Exercise Enable
d08 Frost Setpoint 41ºF (5.0ºC)
41ºF to 63ºF
(5.0ºC -to 17ºC )
Minimum room temperature for frost protection and holiday mode
d09 Hour Format 1
0 12 Hour Time Format (eg. 5:00 pm)
1 24 Hour Time Format (eg. 17:00)
d10 Not Applicable N/A N/A This function is not applicable
d11 Daylight Savings 1
0 Daylight Savings Time (DST) O
1 Daylight Savings Time (DST) On
d12
Max. Heat
Setpoint
95ºF (35ºC)
42ºF to 95ºF
(17.5ºC to 35.0ºC)
Maximum setpoint for heating mode
d13 Max. Cool Setpoint 41ºF (5ºC)
41ºF to 104ºF
(5.0ºC to 40.0ºC)
Maximum setpoint for cooling mode
d14
Floor Sensor High
Limit (heating)
81°F (27°C)
59ºF to 113ºF
(15.0ºC to 45.0ºC)
Disable heat demand when oor temperature is above high limit.
Increment: 1°F (0.5°C)
d15
Floor Sensor Low
Limit (heating)
50°F (10°C)
43ºF to 104ºF
(6.0ºC to 40.0ºC)
Provide heat demand when oor temperature is below low limit.
Increment: 1°F (0.5°C)
d16
Floor Sensor Low
Limit (cooling)
43°F (6°C)
43ºF to 113ºF
(6.0ºC to 45.0ºC)
Disable cooling demand when oor temperature is below low limit.
Increment: 1°F (0.5°C)
d17 Preset Programs 1 0-1
Select program. Once selected, the selected program will overwrite
the present program.
d18
Heat/Cool Mode
Selection
0
0 Disable Heat/Cool selection
1 Enable Heat/Cool selection
Section 7
Setting Device Parameters
AS20WRF/BRF Thermostat – Functions & Parameters
