4.9
Section 4
1 2 3 4 5 6 7
PM
Choosing the AKL Wiring Center device under the All Equipment menu on the SALUS Smart Home
mobile application and pressing the Identify icon will cause the RED G1 & G2 on the device
to ash. Similarly, pressing the Identify icon for the AX10RF device will cause the green LED
backlight on the On/O button to ash.
Auto Manual
On Off
LED is solid red.
AS20WRF/BRF Thermostat with ARV10RFM
Radiator Valve Actuator
To begin pairing, all of the required components are to be powered: AS20WRF/
BRF Thermostat, ARV10RFM Radiator Actuator and AX10RF Receiver (if desired
for boiler demand switching – RX1) and the LED ring on the SG888ZB is solid
blue. The LED indicator on the Actuator should be o. BEFORE PROCEEDING,
Listen to the ARV10RFM to be sure there is no motor activity. If a AX10RF
Receiver is used, the LED back light on the Auto/Manual switch should be
ashing red.
DO NOT BEGIN pairing with the ARV10RFM Radiator Valve Actuator unless the light is
out and there is no motor activity. Listen closely to the Valve Actuator to be sure it is
not operating before proceeding.
Device Pairing & Setup
with Internet Connection
To Next Page
