Information
provided
Explanations Example(s) of screen(s)
FLUSHBOX
• The FLUSHBOX positions the gun so that
the rising and flushing phases occur
automatically without the user having to pull the
gun trigger.
• The user uses this FLUSHBOX (check box)
during the priming and flushing phases.
Dump valve
• Valve positioned on the circuit upstream of
the gun.
• This valve has a larger flow diameter than
the application guns, which allows for an
application guns, which allows for faster priming
or flushing.
Information
provided
Explanations Example(s) of screen(s)
Volumes
and dimensions
• Describe the different volumes in the
dosing system.
• The dimensions to be filled in concern the
part that blinks in red on the screen.
• Opposite examples of different volumes
described.
