Sames PPH 607 - Page 73

Revised A 73 6301
8. PPH 607 SCAR metric spare parts list (continued)
8.1 Robotic mount, 65 EC version (continued)
Item USA P/N Sames P/N Description Qty
1 72-1124-01 1202996 Aluminium cover 1
1a 62-1137-00 1514409 Shaping air assembly 1
2 82-0993-05 J2FENV386 O-ring 84 x 2 teflon encapsulated - viton 1
3 72-1039-02 1202570 Shaping air insert OD: 65mm 1
4 82-0993-04 J2FENV385 O-ring 82 x 1.6 teflon encapsulated 1
5 72-1125-00 1202995 Shaping air shroud 1
5a 82-0410-31 J3STKL014 O-ring 2.5 X 1.25 chemically inert 1
6 72-1123-00 1310370 Shaping air nut OD: 65mm 1
7 J2FENV622 J2FENV622 O-ring 88.62 x 1.78mm, teflon encapsulated 1
8 1309562 1309562 Deflector 1
9 1202905 1202905 Bellcup 65 EC 1
10 1308547 1308547 Clip , 65EC 1
16 1505874 1505874 Turbine motor
(see § 8.8 page 82.)
1
17 X4FVSY068 X4FVSY068 Screw Chc - M3 x 12 stainless steel socket
head
5
20 K6RKBL361 K6RKBL361 Ball bearings see § 6.4.1 page 54 and see §
8.8 page 82)
41
21 82-0410-19 J3STKL005 O-ring 5.28 x 1.78 chemically inert (see § 8.9
page 83)
1
22 738635 738635 Injector, 1.8mm 4 grooves
(see § 8.9 page 83)
1
23 82-0410-31 J3STKL014 O-ring 2.0 x 1.25 - chemically inert
(see § 8.9 page 83)
1
24 X4FVSY068 X4FVSY068 Screw Chc - M3 x 12 stainless steel socket
head
3
25 738354 738354 Injector holder 1
26 640464 640464 Restrictor dia 3.0mm (see § 8.9 page 83)1
27 82-0410-18 J3STKL002 O-ring 3.1 x 1.6 mm, chemically inert
(see § 8.9 page 83)
2
28 1405145 1405145 Solvent injector - stainless steel 1
28a 82-0410-24 J3STKL027 O-ring 2.9 x 1.2 - chemically inert
(see § 8.3 page 77)
2
29 1409802 1409802 Alignment Pin dia.12 (shaping air) - stainless
steel
1
29a 82-0410-23 J3STKL026 O-ring 2.75 x 1.6 - chemically inert (Mic. IN/
OUT)
2
29b 82-0884-26 J3STKL035 O-ring 3.68 x 1.78 - chemically inert 4
29c 82-0884-10 J3STKL078 O-ring 6.07 x 1.78 - chemically inert 6
30 X7CVCB069 X7CVCB069 Screw M3 x 16 brass 1
31 1401208 1401208 High voltage contact 1
32 1506878 1506878 Equipped robotic elbow 1
33 1302692 1302692 Split ring 1
34 1304309 1304309 Elbow nut 1
35 J2FENV638 J2FENV638 O-ring 94.97 x 1.78 mm teflon encapsulated. 1
