8. PPH 607 SCAR metric spare parts list (continued)
8.1 Robotic mount, 65 EC version (continued)
Item USA P/N Sames P/N Description Qty
36 1305059 1305059 Manifold cover extended 1
36a 1201454 1201454 Nut, quick disconnect tightening ring 1
37 82-0410-18 J3STKL002 O-ring 3.1 x 1.6 mm, chemically inert 2
38 640464 640464 Restrictor dia 3.0mm (see § 8.9 page 83.) 1
38a 82-0410-23 J3STKL026 O-ring 2.75 x 1.6 - chemically inert
(see § 9.3 page 86 )
2
39 82-0884-26 J3STKL035 O-ring 3.68 x 1.78 - chemically inert 4
40 1402691 1402691 Alignment pin shaping air - nylon 1
41 82-0884-10 J3STKL078 O-ring 6.07 x 1.78 - chemically inert 6
41a 1403825 1403825 Pin, alignment dia.12 2
42 1508317 1508317 Nano-valve with o-rings
(see § 6.3.1 page 53 and see § 8.5 page 79)
4
42a 1506300 1506300 Equipped manifold body 1
43 1402690 1402690 Solvent injector - nylon 1
43a 82-0410-24 J3STKL027 O-ring 2.9 x 1.2 - chemically inert 2
44 1401208 1401208 High voltage contact 1
44a X7CVCB069 X7CVCB069 Screw M 3 x 16, brass 1
45 759968 759968 Regulator (rebuilding kit only).
see § 6.5.1 page 60 and see § 8.6 page 80,
and see § 9.4 page 88. for option kit -
”By-pass”
1
46 1403758 1403758 Pipette, 6 mm (see § 8.4 page 78)10
46a 82-0884-10 J3STKL005 O-ring 5.28 x 1.78 chemically inert 10
49 1403759 1403759 Pipette, 8 mm (see § 8.4 page 78)6
49a 82-0884-12 J3STKL094 O-ring 7.65 x 1.78 6
51
1305033
1305033 Bracket, pipette 1
51a X9NVFP118 X9NVFP118 Screw M4 x10, cheese head, nylon 3
52 1508750 1508750 UHT 153, high voltage cascade 1
53 X9SVCB232 X9SVCB232 Screw, CH M6 x 50, nylon/fiber glass filled 5
54 - - Tubes fittings and o-rings (see § 8.7 page 81)16
55
1403825
1403825 Pin, alignment dia. 12 2
56 X9NSFA706 X9NSFA706
Cascade set screw M6 x 7 nylon,
Alternate M6 x 8 grub slot set
(see § 5.3.5 page 41 )
1
57 1513090 1513090 Equipped quick disconnect robot plate 1
