Station Name
Enter the name of the system. Along with AE Title, it is often used to identify the system
in the DICOM network.
Port No.
Enter the port number for the server being used.
▐ DICOM Send Format
Specify the storage format for the 2D or Color Mode images for which the DICOM services
will be used. Select either Color or Gray using the Combo button. If you select Gray, images
are saved in grayscale format.
▐ DICOM Compression
Select whether to compress the still images for the DICOM service. Select Uncompressed
or JPEG Baseline by using the Combo button. When you select Uncompressed, the images
are saved without compression.
▐ Destination Group
Use Send to DICOM function to set the destination group for sending images when the User
Defined Key (User Key or Peripheral Key) is pressed.
The set destination group will be displayed under DICOM Destination in the Patient
Information screen. Once the destination group is set and the user defined key is pressed,
image is sent to the destination group designated as DICOM Destination on the Patient
Information screen.
Press Add Group or Edit Group to bring up DICOM Group window.
Add: Add a Destination Group.
Edit: Edit a Destination Group.
NOTE
DICOM Send Format settings begin to apply when an image is saved. For
example, if it is set to Gray, saving an image will save it in grayscale
format.
NOTE
DICOM Compression settings are applied when an image is saved. For
example, if it is set to JPEG Baseline, saving the image will compress it.
