2 - 20 HS70A Service Manual
▌ External Peripheral Devices
These are peripheral devices that can be connected for use when needed and are
connected via the USB port located at the rear panel.
When using a peripheral device via a USB port, always turn the power off before
connecting/disconnecting the device. Connection/disconnection of USB devices
during power-on may lead to malfunction of the system and the USB devices.
NOTE
■ When removing the removable disk, use Utility > Storage manager.
■ USB ports are located both on the control panel and the rear panel of the
console.
We recommend that you connect USB storage devices (flash memory media,
etc.) to the ports on the control panel, and other USB peripheral devices to
the rear panel for convenience.
The following products are recommended:
■ USB Video Printer
– Black and White: Mitsubishi P95DE (Japan: Mitsubishi P95D), SONYUP-D897, SONY
UP-X898MD, SONY UP-D898MD
– Color: Mitsubishi CP-30DW, SONY UP-D25MD
■ USB Line Printer
– Black and White: Samsung ML-2955DW
– Color: Samsung CLP-615ND
CAUTION
■ You must install a printer and driver compatible with the English version of
Microsoft Windows 7. Contact Samsung Medison customer service
department for inquiries about printer driver installation.
■ When connecting the printer, ensure that the printer is configured under
Microsoft Windows or system setup and has been chosen as the default
printer.
■ Please check the port that the printer uses before connecting. Printers should
be connected to the printer port while the USB printer should be connected to
the USB port.
■ USB to RS-232C Serial Cable
USB to Serial (RS-232C) Converter with FTDI Chipset (FTDI FT232BM Compatible)
