Chapter 2. Introduction 2 - 21
For more information about the Open Line Transfer, refer to ‘Chapter 9.
Measurements and Calculations’.
■ Foot Switch
– 3 Pedals HID Type
To configure the foot switch function, go to Utility > Setup > Peripherals > Foot Switch.
You can select one function from the following: Freeze, Update, Record, Print1, Save,
Store Clip, Volume Start, Ez Exam, PD Mode, Color Mode, M Mode, PW Mode, CW
Mode, ElastoScan, TDI Mode, TDW Mode, or Biopsy.
■ Misc.
Flash Memory Media
NOTE
■ The system cannot recognize USB 1.1 flash memory. Remove the flash
memory from the console and equip again with an appropriate device.
■ Regarding file formats that are not ordinarily saved: Please check first to see
if it is possible to save the file format on a desktop PC before trying to save
the file on flash memory.
■ Do not use flash memory media which contain anti-virus programs or are
defective. Otherwise, the product may fail to work properly.
