3 - 18 HS70A Service Manual
▐ Combination Action
 Freeze with
Select a function to execute when the Freeze button on the control panel is pressed.
Available options are BodyMarker, Caliper, AutoCalc, Measure, Text, and None.
- D or M modes only: When 'Freeze with' is set to Measure, Measure Freeze Action
will function only in Doppler and M Modes.
 End Exam with
- None: Tapping the End Exam button on the touch screen exits Exam Mode and
switches the screen to the B Mode Scan screen.
- Patient Window: Tapping the End Exam button on the touch screen switches the
screen to the Patient Information screen.
▐ Multiple Mode
 Simultaneous Mode
You can decide whether to enable Simultaneous Mode in Spectral Doppler Mode, using
the following three options:
- Off: Select this if you do not wish to use Simultaneous Mode.
- Allow B / PW: Select this option if you do not wish to use Simultaneous Mode in
2D/C/PW Modes, but do wish to use it in 2D/PW Mode
- Allow B / C / PW: Select this if you wish to use simultaneous mode for both 2D/PW
and for 2D/C/PW.
 Color Mode Position on Dual Live
Select the position of the Color Doppler Mode in Dual Live Mode.
- Left or Top: Color Doppler Mode is located in the left or upper part of the screen.
- Right or Bottom: Color Doppler Mode is located in the right or lower part of the
screen.
- Left-Right Dual Live Mode Only: The Top-Bottom Dual button disappears when
you check this checkbox.
 Dual Mode
- Show ‘Change Window’ button: Select whether to activate the Change window in
Dual Mode.
