Chapter 3. Installing the Product 3 - 19
Option
You can select multiple items. Use the trackball and the Set button to select and check
or uncheck an item.
- Active HPRF on PW mode: Select whether to activate HPRF (High Pulse Repetition
Frequency), which is supported in PW Spectral Doppler Mode. Check the checkbox
to use the HPRF function.
- Color Map Auto invert(on linear): Check this checkbox to automatically highlight the
Color Map. This is only applied when you change Steer in 2D/C/D Mode, C Mode,
or DPDI Mode in PD Mode.
- M/PW Loop Side by Side: Add Loop Side By Side display in M Mode or Power Spectral
Doppler Mode.
- Width Scale: Automatically fit the image size to the screen size when the depth of a
2D image is adjusted. Please note that this can be only used with linear probes.
- PW mode by M-Line: In 2D Mode, pressing the Set button when M Line is "on" will
take you directly to PW Mode.
▐ Default Text
Show operator name on Scan Image
- Type: Select Diag. Physician, Ref. Physician, or Sonographer. Turn this option off
to hide it from the screen.
▐ Auto Calc.
AutoCalc is a Spectral Doppler Mode feature that automatically performs specific calculations
based on measured values.
Add and remove automatic calculations by using the check boxes. You can select up to six
values.
When the Peak Systolic Velocity and End Diastolic Velocity values are 0, not all results for the
items will be displayed on the screen. In addition, the result value for Time Averaged Mean
Velocity is displayed only when Mean Trace is turned on.
NOTE
The specified items will appear on the screen only when the AutoCalc button
on the touch screen is tapped in Spectral Doppler Mode.
