PR 5211 Instrument Manual ProfiBus Interface
Sartorius EN-71
6.3.1.2 Parameter 2: Scaling Weight Value for 0/4 mA Output
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 WEIGHT MSB
Byte 1 ""
Byte 2 ""
Byte 3 WEIGHT LSB
The weight value is stored at which the analog output is giving 0 or 4 mA.
Default = 0
6.3.1.3 Parameter 3: Scaling Weight Value for 20 mA Output
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 WEIGHT MSB
Byte 1 ""
Byte 2 ""
Byte 3 WEIGHT LSB
The weight value is stored at which the analog output is giving 20 mA.
Default = 3000
6.3.1.4 Parameter 4: Communication
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0
Byte 1
Byte 2
Byte 3 COM 2
1
COM 2
0
The transmission to a remote terminal (e.g. PR 1628) or the SMA protocol can be switched on or off.
COM = 0: switched off,
COM = 1: a remote terminal (e.g. PR 5110) switched on,
COM = 2: SMA protocol switched on,
Default = 1.
