SATO CL4NX User Manual

293
◦ Appears only if you have installed the optional wireless LAN.
• A message prompting you to restart the printer will appear on the Online/Offline screen
if you have made any changes. In such a case, reboot the printer to apply the settings.
[Services]
Set the TCP/IP port number, NTP, LPD, FTP, SNMP, or SOS (SATO Online Services).
The setting items are as follows:
Ports
Set the port number.
NTP
Set the functions for NTP.
LPD
Set the functions for LPD.
FTP
Set the functions for FTP.
SNMP
Set the functions for SNMP.
Online Services
Set the functions for SOS (SATO Online Services).

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
