629
Item Specification
◦ 609 dpi (CL4NX only): 20 to 397 mm (0.79" to 15.63") (with liner: 23
to 400 mm (0.90" to 15.75"))
Cutter mode (cutting every label)
◦ 203 dpi: 35 to 2497 mm (1.38" to 98.30") (with liner: 38 to 2500 mm
(1.50" to 98.42"))
◦ 305 dpi: 35 to 1497 mm (1.38" to 58.94") (with liner: 38 to 1500 mm
(1.50" to 59.05"))
◦ 609 dpi (CL4NX only): 35 to 397 mm (1.38" to 15.63") (with liner: 38
to 400 mm (1.50" to 15.75"))
Cutter (cutting according to the specified number of labels)/Cut &
Print mode
◦ 203 dpi: 54 to 2497 mm (2.13" to 98.30") (with liner: 57 to 2500 mm
(2.24" to 98.42"))
◦ 305 dpi: 54 to 1497 mm (2.13" to 58.94") (with liner: 57 to 1500 mm
(2.24" to 59.05"))
◦ 609 dpi (CL4NX only): 54 to 397 mm (2.13" to 15.63") (with liner: 57
to 400 mm (2.24" to 15.75"))
Dispenser mode
◦ 27 to 397 mm (1.06" to 15.63") (with liner: 30 to 400 mm (1.18" to
15.75"))
Linerless mode (CL4NX only)
◦ 38 to 120 mm (1.50" to 4.72")
Usable Media Types Same as the printer specifications. If the label color is silver or
laminated, however, it makes it difficult for the barcode checker to read
the barcode, as the light of the barcode checker may cause a reflection
on the label surface. Be sure to do a test read carefully in advance.
Readable
Barcode
Orientations
1D
Barcode
Checker
(1) Media feed direction
To Next Page
