Basic Specifications of the Barcode Check Function
630
Item Specification
2D
Code
Checker
(1) Media feed direction
Place the barcode within the size of the visual field. Do a test read
carefully in advance.
1D
Barcode
Narrow bar: 0.25 mm (0.01") or greater
• 203 dpi: 2 dots or more
• 305 dpi: 3 dots or more
• 609 dpi (CL4NX only): 6 dots or more
Refer to the specifications of each barcode checker.
Recommended
Barcode Sizes
2D
Code
Cell size: 0.25 mm (0.01") or greater
• 203 dpi: 2 dots or more
• 305 dpi: 3 dots or more
• 609 dpi (CL4NX only): 6 dots or more
Refer to the specifications of each barcode checker.
The size of the visual field conforms to the specifications of the
barcode checker.
Available Code Formats
The barcode check function supports the following code formats. Check the specifications of the
barcode checker to ensure compatibility with the available code types.
Code Type Available code formats
1D Barcodes CODABAR(NW-7)
CODE39, CODE93, CODE128
JAN/EAN-13/8
UPC-A/UPC-E
