Handling of I/O modules
Orientation
2-10
2
2 43
1
1. Install all four screws, tightening them only to the extent that the PCD can still
be suspended from them.
2. Suspend PCD from screws.
3. Remove the housing cover (grasp the edge of the housing cover with your
ngertipsandpullittowardsyou).
4. Fully tighten the two upper screws.
