System Memory Structure
CPU / Control Process Unit
3-6
3
PLC_SYS
File system for FW user program
data (COB, XOB, FB, PB, SB)
INTFLASH
Micro SD Flash card
DATA
WEBPAGES
LOG
RootdirectoryofanSDashcard
3.5.2 FlashMemoryStructureonPCD1.M2110R1
File system for the user
Primarily used for BacNet
PLClesystemonlyforFW.Theendusercannotaccessthispartition
Used for linked web projects (web builder)
3.5.3 On-BoardMemoryfortheFileSystem
Tousetheon-boardashmemory,select
«PCD Memory» «Internal»
Theinternalashmemoryhasthefollowingname:
INTFLASH.
Theabsolutepathforaccesstotheleisasfollows:
INTFLASH:/MYFOLDER/MYFILE.TXT
