2.6 Labelling
PCD1 I/Os are labelled with two self-adhesive labels. One set of 2 x 4 labels (item
number: 4 310 8748 0) is included with the PCD1.M2_ on delivery. Labels can be
createdwiththeDeviceConguratorandthenprinted.
4 310 8748 0
Set 1
Set 2
Set 3
Set 4
TOP OF PAGE
Saia-Burgess Controls AG, CH-3280 Murten
CreatingI/OLabels
Thedesireddenitionsof
theI/Omodulesusedmustrst
be assigned to the corresponding
slots in the Saia PG5
®
(Version 2.0
orlater)DeviceCongurator.
Start Label Editor.
