4 Inputs and Outputs
This chapter describes the inputs and outputs of the PCD1.M2_ in terms of their
function and pin assignment.
Three possible locations for inputs and outputs are described. These are
- On-board
- As plug-in modules
- On RIOs
4.1 On-board
On-board means mounted “on the CPU mother-board”
In the following overview IO0 is a slot for plugging in expansion modules. The
descriptions of plug-in modules can be found in chapter 4.3.
