3.1 CPU Properties PCD1.M2110R1(Room)
Basic unit PCD1.M2110R1
General Features
I/O bus extension No
Number of inputs/outputs or I/O
module slots
up to 40
1)
Processor MCF5373L / 234 MHz
Firmware,rmwareupdate(rmware
memory soldered on)
Can be downloaded from Saia PG5
®
environment
Programmable with Saia PG5
®
V2.1.030 or higher
RAM expansion 128 Kbyte
Code/Text/DB
256 Kbytes
write-protected)
Backup memory integratedinthelesystem
Userlesystem 8 Mbyte
Hardware time precision Yes, deviation less than 1 min/month
Data backup
Renata CR2032 lithium battery, 1…3 years
2)
Digital inputs
Max. Input frequency
4
1 kHz
3)
Digital outputs Max. 10 (1 relay)
Interfaces
Programming interface USB
4)
Optional serial data interface Port 1
to Slot A
1 × PCD7.F1xxS module
RS-232, RS-422/485, MP-Bus or Bluetooth
Port 0 RS-485 (X3 terminal block),
up to 115 kbit/s

Ether-S-Net interface 2 Port Switch
Field bus connections
Serial-S-Net

1)
With digital I/O modules PCD2.E16x or PCD2.A46x, each with 16 I/O
2)
 Thespeciedtimeperiodisabu󰀨ertime,whichdependsontheambienttemperature(thehigher
thetemperature,theshorterthebu󰀨ertime)
3)
The 1 kHz applies with a pulse/pause ratio of 1:1 and is based on the overall frequency of the
inputs.
4)
The USB port is type “USB 1.1 Slave Device 12 Mbps” and can only be used for programming
andasanS-Busslaveincombinationwithspecicsoftwareproducts(Webconnect,ViSi-PLUS
with S-Driver). With a USB 2.0 hub the download takes place twice as fast. It can also be used as
a serial data port, for example, in order to connect a terminal; however, this impedes the commis-
sioning and troubleshooting with the Debugger.
