5 System Cables and Adapters
System Cables with I/O Module Connections to the PCD
Toeliminatesourcesoferrorandsavetime,variouspre-conguredcablesare
available. The module plug is already mounted at the end of the cable. Conse-
quently, that end only has to be plugged in. Depending on type, the other cable
endwilleitherhaveaatcableconnectorfortheterminaladaptersorrelayinter-
face, or alternatively individual 0.5 mm2 or 0.25 mm2 wires, numbered and colour-
coded.
Cables with various connection technologies are described in the
Manual 26-792 “System Cables and Adapters”.
