System Memory Structure
CPU / Control Process Unit
3-8
3
3.5.5 FlashmemorymodulePCD7.R5xxforFileSystem
PCD7.R5xx
FlashcardstatusLED(yellow)switchesonwhentheashcardisaccessed.
Theashcardisinserteddirectlyintothemaincircuitboard.Ascrewinthecover
securestheashcardinplace.Themechanicalcoverisdesignedsothattheash
card cannot loosen from the slot due to vibrations.
Summary Memory Module for PCD1.M2_ CPU
PCD7.R550M04 FlashmemorymodulewithlesystemEnablesthesavingofles,such
asthoseforthewebserver.ThePCDcanaccessthelesdirectlythroughthe
FTPorHTTPserverandwriteallPC-readableles(*.csv)directlytothemod-
ule.
PCD7.R560
BACnet
®
rmwaremoduleforslotM1
PCD7.R562
BACnet
®
rmwaremoduleforslotM1
with128MBforprogramstorageandlesystem
PCD7.R580
LonoverIPrmwaremoduleforslotM1
PCD7.R582*
LonoverIPrmwaremoduleforslotM1
with128MByteforprogramstorageandlesystem
