Firmware Version for the PCD1.M2_ (COSinus update)
CPU / Control Process Unit
3-4
3
3.4 FirmwareVersionforthePCD1.M2_(COSinusupdate)
ThermwareofthePCD1isstoredonaashmemory,whichissolderedtothe
motherboard.Armwareupdatecanbeappliedbydownloadinganewversion
with the Saia PG5
®
. To do so, proceed as follows:
● Open www.sbc-support.comanddownloadthelatestrmwareversion
● Establish a connection between Saia PG5
®
and the CPU, the same way as
when downloading an application (in accordance with the available devices,
serial with PGU cable, modem, USB, Ethernet)
A modem connection is never permitted. Modems can block, so that
remote access is no longer possible. In these cases, it is necessary to
visit the system in person. Other connection options are preferred.
● Opentheonlineconguratorandgoo󰀪ine
● In the Tools menu, select “Update Firmware” and use the Browse function
toselectthepathforthelewiththenewrmwareversion.Makesurethatonly
oneleisselectedfordownload
● Start the download
● After the download, the power supply of the PCD1 may not be interrupted
for 2 minutes. (CPLD programming sequence). Otherwise, there is the risk
that the CPU locking, in which case it must be sent back to the manufacturer.
The download process is concluded with the restarting of the PCD.
ThermwareofthePCD1.M2_issecuredonaashmemoryonthemother-
board.
