SBC PCD1.Room - Page 56

Hardware Manual PCD1.M2110R1 │ Document 27-619 │ Version ENG 04 │ 2018-08-20
Saia-Burgess Controls AG
On-board│AnalogueInputs
Inputs/Outputs (I/O)
4-12
4
Connection concept
+
-
+
-
11 12 13 14 15 16 17 18 19
10
9 8 7 6 5 4 3 2 1
0
I2 I3 I1 I0
X1
IX0 IX1 AI0 AI1 -
O0 O2 O3 O1 IO5 IO4 IO6 IO7
X0
Uext.
GND
+
-
Pt 1000
Ni 1000
Resistance
PWO or
O8
-10...+10 VDC
0...20 mA
Connectionconceptfortwo-wiretransmitters
11 12 13 14 15 16 17 18 19
10
9 8 7 6 5 4 3 2 1
0
4...20 mA*
0...20 mA
δ
υ
I2 I3 I1 I0
O0 O2 O3 O1 IO5 IO4 IO6 IO7
X0X1
Uext.
GND
IX0 IX1 AI0 AI1 -
+
-
24 VDC
PWO or O8
*4..20mAthroughtheuserprogram
or in the PG5 DeviceCongurator Media Mapping
