14.2.0. Cleaning Roller
In case of feed roller, wipe with slightly dampened cloth with alcohol. While rotating one side of the roller
manualy, stick the cloth into the other side of the roller.
Clean the rollers as described below everyday after working
14.3.0. Cleaning Dust trap
SB-3000 is designed that prevents for
Misrecognition and malfunction by 3
kinds of “Dust traps” at the locations on
right figure. They collect dust when the
machine is running.
As you see each location on right figure,
it’s required wiping off the dust with
a cloth putting alcohol once a month.
Dust Trap A①
Dust Trap B②
Dust Trap C③
Pick up Rollers ADF Roller
Press Roller
Separate Rollers
① ② ③
To Next Page
