2.0.0. DESCRIPTION OF THE PARTS
2.1.0. EXTERIOR VIEW
2.1.1. FRONT VIEW
2.1.2. REAR VIEW
BILL GUIDE
CONTROL PANEL
POCKET LED
STACKER #1
STACKER #2
REJECT POCKET
FRONT DOOR
POWER SWITCH
DUST CAP
REAR DOOR A
REAR DOOR B
AC POWER
INTERFACE
HOPPER
OPEN HANDLE
(FIG 3-01)
(FIG 3-02)
FRONT DOOR
