SBM SB-3000 - Pulley

24
2.3.3. PULLEY
No
Part Name No
Part Name
1 PULLEY_ADF_V_S3M-40 8 PULLEY_STEP_MOTOR_S3M_15
2 PULLEY_ADF_CLUTCH40 9 PULLEY_S3M_18
3 PULLEY_ADF_S3M-40 10
PULLEY_S3M_16
4 PULLEY_FEED 11
PULLEY_FEED_4_V_S3M-32
5 PULLEY_FEED_1_V_S2M-24 12
GEAR_M08_T35-2
6 PULLEY_S3M-20 13
GEAR_M08_T35
7 PULLEY_FEED_1_V_S2M-24
: Forward part,
: Backward part
1
2
3
4
5
5
5
5
6
6
7
8
8
10
11
4
6
12
6
13
6
4
6
9
