156

10. TRANSFER A ASSY AND HOPPER GUIDE ASSY

TRANSFER A ASSY AND HOPPER GUIDE ASSY

NO.

CODE PART NAME Q`TY

1 721018400A HOPPER_GUIDE 1

2 8400E034XA SCREW_T/P_PH_T2_Ø3X8_Fe_Zy 4

3 - TRNASFER_A_ASSY 1

4 8400E025XA SCREW_M/C_PH/SWW_M4X8_Fe_Ni 4
