164

18. RAINFORCE PLATE ASSY

RAINFORCE PLATE ASSY

NO.

CODE PART NAME Q`TY

1 - COVER_FRONT_ASSY 1

2 8400E021XA SCREW_MC_PH_SWW_M3X6_FE_ZY 2

3 8400E025XA SCREW_M/C_PH/SWW_M4X8_Fe_Ni 10

4 - HINGE_BODY_BTM_ASSY 1

5 741012200A REINFORCE_PLATE_DETECT 1

6 741014100A REINFORCE_PLATE_BOTTOM 1
