SBM SB-3000 - Page 191

191
ASS'Y_TRANSFER_B_BOTTOM
NO.
CODE PART NAME Q`TY
1 8400E021XA SCREW_M/C_PH/SWW_M3X6_Fe_Zy 4
2 8400E034XA SCREW_T/P_PH_T2_Ø3X8_Fe_Zy 7
3 721020700A GUIDE_LENS_STACKER 4
4 721022700A LENS_TRANSFER_B 4
5 1A10X1199A ASS'Y_CROWN_TRANSFER_ROLLER_PINCH_S 1
6 1A10X1195A ASS'Y_CROWN_EXIT_ROLLER 1
7 8400E021XA SCREW_M/C_PH/SWW_M3X6_Fe_Zy 4
8 7810A114XA BUSH_TRANS_C 2
9 1A10X1198A ASS'Y_CROWN_TRANSFER_ROLLER_PINCH 1
10
721024500A TRANSFER_GUIDE_B_BOTTOM 1
11
8400A003XA E_RING_Ø5(5x11x0.6)_Fe_ZB 2
12
8400D010XA PLASTIC_WASHER_Ø6(6.2x10x_0.5T) 2
13
7810A101XA SHAFT_TRANSFER_B 1
14
8400E033XA SCREW_T/P_PH_T2_Ø3X6_Fe_Zy 4
15
- HANDLE_TRNS_B ASSY 1
16
721021600A DUST_COVER 1
17
721021900A DUST_COVER_OUTLET 1
18
741013800A BKT_TRANSFER_GUIDE_B 1
19
7610A036XA TORSION_SPRING_OPEN_L 1
20
7610A037XA TORSION_SPRING_OPEN_R 1
21
8210A038XA SE_BELT_2 2
