13-7. ASS'Y_DETECT_CASE_BOTTOM
ASS'Y_DETECT_CASE_BOTTOM ( 2/6)
NO.
CODE PART NAME Q`TY
1 8400E033XA SCREW_T/P_PH_T2_Ø3X6_Fe_Zy 8
2 1A10X1156A SB-3000 UVA V1.3 1
3 720713800A CAP_RP2_V 3
4 8810E097XA BLOCK_DUSTPAN 2
5 7810A117XA SHAFT_DUST_PAN 1
6 1A10X1211A ASS`Y_ROLLER_PINCH_FEED-1 1
7 1A10X1166A SB-3000 RP3_TRN V3.0 1
8 720713500A CAP_RP1_V 3
9 - DETECT_MODULE_OUT_ASS`Y ( 1/6 ) 1
