216

21. ROLLER_PINCH_FEED

07-ROLLER_PINCH_FEED

NO. CODE PART NAME Q`TY

1 8400A005XA E_RING_Ø7(7x14x0.8)_Fe_ZB 6

2 8210A034XA BEARING L1910ZZ 3

3 7610A035XA COIL_SPRING_PINCH(SHAFT) 3

4 7810A093XA SHAFT_PINCH_FEED 1

22. ROLLER_PINCH_MR

08-ROLLER_PINCH_MR

NO.

CODE PART NAME Q`TY

1 8400A003XA E_RING_Ø5(5x11x0.6)_Fe_ZB 2

2 7810A103XA SHAFT_PINCH-MR 1

3 800703200A ROLLER_PINCH_V 1

4 7610A039XA TORSIOIN_SPRING_PINCH_E 1
