223

28. MECH_OUTLET ASS'Y

MECH_OUTLET ASS'Y

NO.

CODE PART NAME Q`TY

1 8405E049XA SCREW_M/C_PWH_M3X6_Fe_Ni 1

2 741015500A STOPPER_OPEN_LOCK 1

3 741013600A HINGE_DOOR 1

4 8400E025XA SCREW_M/C_PH/SWW_M4X8_Fe_Ni 2

5 741014300A HINGE_BODY_BTM 1

6 8400A002XA E_RING_Ø4(4x11x0.6)_Fe_ZB 1

7 7610A046XA TORSION_SPRING_HINGE_DOOR 1

8 7810A121XA STOPPPER_HINGE_SPRING 1

9 8400A005XA E_RING_Ø7(7x14x0.8)_Fe_ZB 1
