OUTLET ASSY 6
NO. CODE PART NAME Q`TY
1 8400A003XA E_RING_Ø5(5x11x0.6)_Fe_ZB 4
2 8200A004XA BEARING_LF_1360ZZ 4
3 721020900A GUIDE_SELECTOR (SB3000) 2
4 8405E047XA SCREW_M/C_PH_M3X8_Fe_Zy 4
5 7810A085XA SHAFT_SELECTOR_CONNECTOR 2
6 741011900A BKT_SELECTOR(SB3000) 2
7 8400E025XA SCREW_M/C_PH/SWW_M4X8_Fe_Ni 2
8 8600B002XA SOLENOID 2
9 8400E021XA SCREW_M/C_PH/SWW_M3X6_Fe_Zy 2
10 1A10X1174B SB-3000 MOVE_OVERFLOW V5.0 2
11 1A10X1221A ASS'Y_STACKING_POSITION_BAR 2
12 8410E078XA SCREW_T/P_PH_T2_Ø2.X10_Fe_Zy 2
-
11 1A10X1221A ASS'Y_STACKING_POSITION_BAR 1
A 721023600A STACKING_POSITION_BAR 1
B 741015400A OVERFLOW_PLATE 1
C 8400E032XA SCREW_T/P_PH_T2_Ø2.6X6_Fe_Zy 1
To Next Page
