OUTLET ASSY 9
OUTLET ASSY 9
NO. CODE PART NAME Q`TY
1 1A10X1228A ASS'Y_BKT_LATCH_DOOR 2
2 8400E021XA SCREW_M/C_PH/SWW_M3X6_Fe_Zy 4
A 741014500A BKT_LATCH_DOOR 1
B 7610A034XA SPRING_LATCH_DOOR 1
C 721025500A LATCH_DOOR_A 1
D 8400A002XA E_RING_Ø4(4x11x0.6)_Fe_ZB 1
