Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07 7 Parameter menu
CAUTION: 50% means nominal output speed (50Hz) and 100% meens that the output speed
is 2 times faster (100Hz)
7.4 Parameter group: Ramp (optional)
The start ramp can be set separately for each operation mode. Thus, a 100% start ramp means
that the motor attains its maximum speed in about a second. Higher speeds (see section 7.3) lead to shorter
runtimes. If the ramp is set below 100%, the starting time increases in an inversely proportional fashion.
Menu item
Sub-menu
item
poss. setting Notes / comments
P5.1 Ramp Local 5. . . 100% Start ramp for local operation
P5.2 Ramp Remote 5. . . 100% Start ramp for remote operation
P5.3 Ramp Emergency 5. . . 100% Start ramp for emergency operation
7.5 Parameter group: Control
Menu item
Sub-menu
item
poss. setting Notes / Comments
P6.1 Steuerung
Phase
sequence
off (0)
Phase sequence detection is deactivated. A wrong
phase sequence will not be shown on the display
and also not corrected. In case of wrong phase
sequence the actuator will drive in the wrong
direction.
on (1)
Phase sequence detection is activated. A wrong
phase sequence will be shown on the display but
not corrected. In case of wrong phase sequence
the actuator cannot be driven electrical.
auto (2)
The phase sequence will be corrected
automatically. The actuator will always drive in the
right direction.
P6.2 Control Ready delay 0 - 10 sec. Drop-out delay for the ready signal (Bin. outputs)
P6.3 Steuerung
Failsafe-
funktion
0: Aus
Only for failsafe actuators!
This value must correspond to the mechanically
realized Failsafe function!
1: Auf
2: Zu
P6.5
2)
Control 24V output 0
24V auxiliary output is deactivated (chapter 19.5,
page 55). The function of the auxiliary input is still
activated.
{1}
24V auxiliary output is activated (capter 19.5, page
55).
7.6 Parameter group: Password
The actuator control can be password-protected to prevent access at different levels. It is possible to prevent
entry by unauthorized personnel or to entirely lock motor operation.
Default password is set to "000" and thus deactivated.
You can use both numbers and capital letters in your password. After entering a password, password protec-
tion is activated. To remove password protection, enter an empty password (000).
When accessing a password-protected parameter, the user is automatically prompted to enter the password.
Only after correctly entering the password, it is possible to change the corresponding parameters.
2)
since firmware 1.303
27
