14 Recommendations of Lubricants (for all manufactures)
Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07
14.2 Spur Gears (actuator size AB8 - AB80)
Lubricating grease DIN 51826 - KPF -1/2 G-20
i.e. High-graphite, bitumen-free permanent lubricant with outstanding EP properties:
Work penetration 0.1mm: between 265 and 340.
Observe operating temperature range!
14.3 Output Drive Type A and Spindle Drive (Linear Actuators)
Lubricating grease DIN 51862- G 1 -G
i.e. Water-resistant complex grease on Al soap basis, highly resistant to acids and alkalines:
work penetration 0.1 mm around 265
Dripping temperature: about 260
◦
C
NLGI grade: 1
Acid-free, not or only marginally reacting with water
Observe operating temperature range!
14.4 Precision Components
Lubricating grease (or spray) DIN 58396- S1
i.e. High-creeping, water-displacing, low-viscosity grease chemically neutral to copper and plastics:
Work penetration 0.1mm: 175 to 385
Dripping temperature: over 150
◦
C
Evaporation loss: max. 1%
Water resistance:
Evaluation grade DIN
51807-1-40
Observe operating temperature range!
14.5 Basic Lubricant Service Interval
On actuator maintenance, the old grease must be removed completely and replaced by a new one.
The service interval for Schiebel actuators is 10 years from the date of delivery
by Fa. SCHIEBEL Antriebstechnik Gesellschaft m.b.H, A-1230 Vienna
The functionality and operating life of the lubricants is, however, dependent upon operational
conditions. It may be necessary to take reduction factors into account.
Operational condition(s) Definition
Reduction
Factor(Multiplier)
On-period (OP) (Total of motor running time)
Extremely high OP over 1,250 hours/year 0,5
High OP over 500 hours/year 0,7
Extremely low OP less than 0.5 hours/year 0,8
Ambient temperature (Permanent or long-term)
Extremely changing between -10 and +50
◦
C 0,5
Extremely high over +50
◦
C 0,7
Extremely low below -25
◦
C 0,9
Output speed (at main shaft of actuator)
High revolution over 80 rev./min 0,8
Utilization factor (with respect to nominal performance)
Very high over 90% 0,8
High between 80 and 90% 0,9
