Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07
SEC-OM-ENGLISH-CSC-V2.08-2019.11.07
Operating instructions for actuators type AB
with SMARTCON control unit
1 Introduction/Notes
These operating instructions apply to SCHIEBEL actuators of the type AB with integrated SMARTCON control
unit.
The scope of application covers the operation of industrial valves, e.g., globe valves, gate valves, butterfly
valves and ball valves. For other applications please consult with the factory.
The manufacturer shall not be liable for incorrect use and possible damage arising thereof. The risk shall be
borne solely by the user.
Using the unit as intended also entails the observance of these operating instructions!
When operating electrical equipment, certain parts inevitably carry hazardous voltage levels. Work
on the electrical system or equipment must be carried out only in accordance with electrical regulations by a
qualified electrician himself or by specially instructed personnel under the control and supervision of a qualified
electrician.
Maintenance instructions must be observed as otherwise the safe operation of the actuator cannot be guaran-
teed.
Failure to follow the warning information may result in serious bodily injury or property damage. Qualified
personnel must be thoroughly familiar with all warnings contained in this operating manual.
Proper transport, storage, installation, assembly and careful commissioning are essential to proper and safe
operation.
When working in potentially explosive areas, observe the European Standards EN 60079-14 ”Elec-
trical Installations in Hazardous Areas” and EN 60079-17 ”Inspection and Maintenance of Electrical
Installations in Hazardous Areas”.
Maintenance work on open actuators may only be conducted if these are de-energized. Reconnec-
tion during maintenance is strictly prohibited.
2 General
2.1 Overview
Figure 1: 1. . . Motor, 2. . . Connection compartment, 3. . . SMARTCON control unit, 4. . . Operating unit,
5. . . Handwheel, 6. . . Signalling lid, 7. . . Lever for manual operation
4
