SCHIEBEL AB Series User Manual

Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07 7 Parameter menu
continued from previous page
Menu item
Sub-menu
item
poss. setting Notes / comments
Closed
Actuator moves on signal failure of external actual
values to the CLOSED position.
Emergency
position
Actuator moves on signal failure of external actual
values to the EMERGENCY position (see param
P13.7)
P14.13
PID-
controller
Calibration of
ext. actual
value
-10.0 – 10.0%
Calibration process: By applying 20 mA to the
external actual value input, this parameter is
corrected until the readout matches to 20 mA.
7.14 Parameter group: PROFIBUS DP (option)
PROFIBUS DP defines the technical and functional characteristics of a serial field bus system, which can be
networked with distributed digital automation devices. PROFIBUS DP is designed for the data exchange at the
field level.
Central control devices such as PLC or PC communicate via a fast serial connection with distributed field de-
vices such as input/output devices, valves and actuators.
Data exchange with these distributed devices is cyclical. The communication functions required to that end are
defined by the PROFIBUS DP basic functions in accordance with EN 50 170.
The PROFIBUS DP option is a hardware option with which you should already be familiar upon
ordering the actuator.
Subsequent installation of hardware components is possible but should only be performed by a pro-
fessional SCHIEBEL installer or specially trained personnel.
The PROFIBUS-DP interface is described in the separate manual "Profibus-DP for SMARTCON controllers".
7.15 Parameter group: DeviceNet (option)
The DeviceNet
R

field bus is based on the CAN protocol and was originally developed by Rockwell Automa-
tion as an open field bus. Today, DeviceNet falls under the responsibility of ODVA (Open DeviceNet Vendors
Association, Inc., http://www.odva.org) as an umbrella organization. DeviceNet is defined in EN 50325 2 and
in IEC 62026 3. DeviceNet is a simple and powerful field bus system for the lowest field bus level to connect
sensors and actuators (slaves) with the associated controllers in a network.
The DeviceNet option is a hardware option with which you should already be familiar upon ordering
the actuator.
Subsequent installation of hardware components is possible but should only be performed by a pro-
fessional SCHIEBEL installer or specially trained personnel.
The DeviceNet interface is described in the separate manual "DeviceNet for SMARTCON controllers".
7.16 Parameter group: Characteristic curves (optional)
With this option, customers can enable travel-dependent torque characteristic curves.
With these characteristic curves, torque limits already set under menu item P2 (torque), can be
further reduced depending on travel. Characteristics can be configured via the infrared interface
with the SMARTTOOL software. (see Figure 64, page 40)
