7 Parameter menu
Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07
continued from previous page
Menu item
Sub-menu
item
Poss. setting Notes / comments
24: Lock Closed
Trigger lock CLOSED (in LOCAL and REMOTE
mode). Actuator moves with the highest priority to
CLOSED; command continues internally active
after reaching the end position CLOSED. Dropping
only with LOCK OFF, Supply OFF or operating
mode OFF.
25: Lock Off Drop the lock
26: Failsafe
Trigger the failsafe function in all operating modes
(only functional in failsafe actuators).
27: Failsafe inv. As Failsafe but active low
28: Lock Open
inv.
As Lock Open but active low
29: Lock Closed
inv
As Lock Closed but active low
30: Lock Off inv. As Lock Off but active low
31: Intermediate
position 1
Approach intermediate position 1 (P8.1) in
REMOTE mode (fix position approach). There is no
repositioning upon reaching the intermediate
position within the hysteresis (see P8.6) Higher
priority than intermediate position 2, 3 and 4
32: Intermediate
position 2
As intermediate position 1 but with higher priority
than intermediate positions 3 and 4
33: Intermediate
position 3
As intermediate position 1 but with higher priority
than intermediate position 4
34: Intermediate
position 4
As intermediate position 1 but with lowest priority.
35: Emergency
position
Approach emergency position (P 8.5). As
intermediate position 1 but with higher priority than
intermediate positions 1, 2.
36: Intermediate
position 1 inv.
As Intermediate position 1 but active low
37: Intermediate
position 2 inv.
As Intermediate position 2 but active low
38: Intermediate
position 3 inv.
As Intermediate position 3 but active low
39: Intermediate
position 4 inv.
As Intermediate position 4 but active low
40: Emergency
position inv.
As Emergency position but active low
P9.2 Bin. Input Input 2 see Input 1
P9.3 Bin. Input Input 3 see Input 1
P9.4 Bin. Input Input 4 see Input 1
P9.5 Bin. Input Input 5 see Input 1
7.9 Parameter group: Binary outputs
The controller is equipped with 8 freely configurable binary outputs. Please find further information on technical
data of the binary outputs in section 19.2, page 54. Provided with external supply, binary outputs are optically
isolated from the rest of the controller.
30
