SCHIEBEL AB Series User Manual

Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07 7 Parameter menu
Default binary outputs are as follows:
Output 1: Ready Output 2: End position OPEN
Output 3: End position CLOSED Output 4: Run OPEN
Output 5: Run CLOSED Output 6: Torque
Output 7: LOCAL Output 8: REMOTE
Menu item
Sub-menu
item
poss. setting Notes / comments
P10.1 Bin. Output Output 1 0: User defined Optional
1: Ready Actuator is ready
2: Fault General fault; actuator is not ready
3: Open Actuator is in open position
4: Closed Actuator is in closed position
5: Running Open Actuators runs in direction Open
6: Running
Closed
Actuators runs in direction Closed
7: Runing Actuator is running in either Open or Closed
8: Torque Open
Switch-off torque was reached in Open direction,
actuator has been switched off
9: Torque Closed
Switch-off torque was reached in Closed direction,
actuator has been switched off
10: Torque
Switch-off torque was reached in either Closed or
Open direction
11: Travel Open The Open end position has been reached
12: Travel
Closed
The Closed end position has been reached
13: Pos. > Int.1 Position > Intermediate position 1
14: Pos. < Int.1 Position < Intermediate position 1
15: Pos. > Int.2 Position > Intermediate position 2
16: Pos. < Int.2 Position < Intermediate position 2
17: Pos. > Int.3 Position > Intermediate position 3
18: Pos. < Int.3 Position < Intermediate position 3
19: Pos. > Int.4 Position > Intermediate position 4
20: Pos. < Int.4 Position < Intermediate position 4
21: Local Local oerating mode (selector switch in position)
22: Remote
Remote operating mode (selector switch in position
Remote)
23: Off
Off operating mode (selector switch in the Off
position)
24: no function no function
25: motor error
The motor temperature sensor has reported an
error
26: Always Signal is always on
27: Never Signal is always off
28: Bin. Input 1 Forwarding of binary input to output
29: Bin. Input 2 Forwarding of binary input to output
30: Bin. Input 3 Forwarding of binary input to output
31: Bin. Input 4 Forwarding of binary input to output
32: Bin. Input 5 Forwarding of binary input to output
continued on next page
31
