SCHIEBEL AB Series User Manual

Operating instructions for actuators type AB with SMARTCON control unit
OM-ENGLISH-CSC-V2.08-2019.11.07 7 Parameter menu
7.17 Parameter group: Identification (optional)
This option allows entering further custom-identification parameters.
Menu item
Sub-menu
item
poss. setting Notes / comments
P18.1 Identification PPS number 15 digits
Used to enter a PPS number. This is displayed in
the bottom line. CAUTION: Param P20.5 must be
set to 0.
7.18 Parameter group: System parameters (locked)
Used for actuator configuration and not available for customers.
7.19 Parameter group: Miscellaneous
Menu item
Sub-menu
item
poss. setting Notes / comments
P20.1 Miscellaneous Language 0: German Defines the menu language
1: English
2: Russian
3: Czech
4: Spanish
5: French
6: Italian
7: Danish
8: Hungarian
P20.2 Miscellaneous
Rotate
display
no Default setting
yes
Rotates the display by 180
◦
Warning: The operation of the control switch and
the selector switch keeps the same.
P20.3 Miscellaneous
Load
configuration
Customer conf. -
Actuator parameters, excluding params P1.1 to
P1.6, will be overwritten with customer parameters.
Customer conf. +
Actuator parameters, including params P1.1 to
P1.6, will be overwritten with customer parameters.
Backup
parameters -
Actuator parameters, excluding params P1.1 to
P1.6, will be overwritten with factory parameters.
Backup
parameters +
Actuator parameters, including params P1.1 to
P1.6, will be overwritten with factory parameters.
P20.4 Miscellaneous
Save
configuration
Customer conf. Stores all parameters in the customer configuration.
P20.5 Miscellaneous Info line {0} - 31
The fourth line of the display shows various
diagnostic values.
P20.6 Miscellaneous Infrared Off (0) The infrared connection is disabled.
On (1)
The infrared connection is activated for about 3
minutes.
41
