Technical data
Connection data of the integrated IO-Link sensor (variant IOL)
Designation PGL-plus-P-IOL
Nominal voltage [VDC] 24
• Min.
18
• Max.
30
Residual ripple supply voltage
[% Vss]
≤ 2
Nominal current [mA] ≤ 200
Short circuit protection yes
Inverse-polarity protection yes
Material, sensor housing PBT GF15 / stainless steel 430 f
Material, active sensor surface PBT GF20
Cable connector M8 connector, 4-pin
Specification: V1.1
Transmission rate COM2
Port ClassA
Protection class IP, Sensor 67
Protection class, sensor 3
Ambient temperature [°C]
• Min. Sensor
-25
• Min. Product
5
• Max. Sensor, Product
70
Max. Linearity deviation from
the final value [%]
1.5*
Resolution [mm] 0.025*
Detectable workpiece difference
[mm]
0.1*
Max. Temperature error from
the final value [%]
3*
Response time / typ. Switching
time / cycle time [ms]
2.7
* Values apply at nominal operating pressure (6bar), room
temperature (23°C), gripping height at point "P" (see catalog)
and when operating without air purge. Deviations may occur
with other parameters.
More technical data is included in the catalog data sheet.
Whichever is the latest version.
